Details
When describing a fat bike, you wouldn’t typically describe it as agile. That’s where the Voytek is different. We paired a narrow pedal stance--aka Q factor--with aggressive XC race geometry to build a fat bike that can intuitively handle snowy trails like your mountain bike can handle summer singletrack.
Specs
Frame | Voytek™ patented carbon frame, Tuning Chip™ dropout system, 177x12 rear hub spacing, Plus-Fat Narrow Q-factor design with PF107BB, guided internal rear derailleur routing, accommodates internally routed dropper post, external brake routing, downtube and chainstay protectors, matching allow bottle cage bolts |
---|---|
Fork | Voytek™ rigid carbon fork, suspension corrected, tapered steerer tube, 485mm axle-to-crown, 51mm offset |
Headset | Wolf Tooth Precision Headset, IS42/IS52 |
Rims/Wheels | Wheels Lithic sealed cartridge bearing 6-bolt rotor hubs with tubeless ready 70mm Lithic Rhyolite aluminum rims. Tubeless kit upgrade available. |
Tires | Schwalbe Jumbo Jim 26 x 4.0 LiteSkin |
Crankset | Race Face Aeffect 83mm with 175mm crankarms and custom offset Wolf Tooth CAMO system, 32T chainring (size Small frame ships with 170mm crankarms, 170mm crankarms are available on other sizes by request) |
Bottom Bracket | Race Face, PF107, Ø41mm |
Chain | Shimano SLX 12-speed |
Rear Cogs | Shimano SLX M7100, 10-51t, 12-speed |
Shifters | Shimano SLX M7100 Trigger, 12-speed |
Handlebars | Race Face Ride, 740mm riser |
Tape/Grips | Wolf Tooth silicone grips |
Stem | Race Face Ride (60mm standard. Other lengths available by request) |
Brakes | Magura MT4 |
Saddle | WTB Volt |
Seat Post | Race Face Ride, 30.9mm |
Sizes | S, M, L, XL |
Weight | 25.4 lbs with rigid fork set up tubeless |
* Subject to change without notice.
